Je bekijkt pagina 25 van 36
German Light Products®
Impression® FR1 User Manual 25
8. DMX channel layout
Normal mode (16 DMX channels)
Channel
Function
Description
DMX
range
Default
DMX
% Range*
Fade
1
Pan coarse
-314.5° to +314.5° (16 bit)
0 – 65535
32768
0 – 100%
Fade
2
Pan fine
3
Tilt coarse
-105° to +105° (16 bit)
0 – 65535
32768
0 – 100%
Fade
4
Tilt fine
5
Color presets
(virtual color
wheel)
RGBW control
Color 01 - Red
Color 02 - Amber
Color 03 - Warm yellow
Color 04 - Yellow
Color 05 - Green
Color 06 - Turquoise
Color 07 - Cyan
Color 08 - Blue
Color 09 - Lavender
Color 10 - Mauve
Color 11 - Magenta
Color 12 - Pink
White – CTO
White
White – CTB
Rainbow effect stop
Rainbow effect active
Random colors slow – fast
0 – 7
8 – 15
16 – 23
24 – 31
32 – 39
40 – 47
48 – 55
56 – 63
64 – 71
72 – 79
80 – 87
88 – 95
96 – 103
104 – 111
112 – 119
120 – 127
128
129 – 223
224 – 255
0
0 – 2.5%
3 – 5.5%
6 – 9%
9.5 – 12%
12.5 – 15%
15.5 – 19.5%
20 – 21.5%
22 – 24.5%
25 – 27.5%
28 – 31%
31.5 – 34%
34.5 – 37%
37.5 – 40.5%
41 – 43.5%
44 – 46.5%
47 – 49.5%
50.2%
50.5 – 87.5%
88 – 100%
Snap
Fade
Fade
6
Red
Color mixing - Red
0 – 255
255
0 – 100%
Fade
7
Green
Color mixing - Green
0 – 255
255
0 – 100%
Fade
8
Blue
Color mixing - Blue
0 – 255
255
0 – 100%
Fade
9
White
Color mixing - White
0 – 255
0
0 – 100%
Fade
10
Shutter / strobe
Shutter closed
Shutter pulse random
Fade on, snap off (random
patterns)
Snap on, fade off (random
patterns)
Fade on, fade off (random
patterns)
Strobe with blackout pause
Strobe effect slow - fast
Shutter open
0 – 15
16 – 47
48 – 79
80 – 111
112 – 143
144 – 199
200 – 239
240 – 255
255
0 – 5.5%
6 – 18.5%
19 – 31.5%
32 – 43.5%
44 – 62.5%
63 – 77.5%
78 – 94.5%
95 – 100%
Snap
Fade
Fade
Fade
Fade
Fade
Fade
Snap
11
Dimmer coarse
Intensity 0 – 100%
0 – 65535
0
0 – 100%
Fade
12
Dimmer fine
13
CTC
RGBW raw
CTC 10 000 K – 2500 K
0 – 15
16 – 255
0
0 – 5.9%
6 – 100%
Snap
Fade
