German Light Products®
Impression® FR1 User Manual 19
6. Control menus and LCD display
Warning! DMX control is disabled when the control menus are active. Be
prepared for the head to move as soon as you exit the control menus.
The control panel and LCD display provide access to user settings, readouts, and
utilities.
When power is applied, the fixture resets and impression and FR1 appear the display
panel. After the reset has completed, the main menu is displayed:
V:1.15/NE 582
198
-214
Next
215
DMX Start Address
Mode
Enter
Down
UP
O
O
O
O
Figure 8. Main menu
See Figure 8. From left to right, the top line of the main menu displays:
Main CPU software version
DMX control mode: N (Normal)
Dimming curve: L (Linear), S (Soft) or E (Extra Soft)
PWM frequency.
In the example shown in Figure 8, the fixture is running CPU software version 1.15. The
fixture is in Normal DMX control mode and set to the Extra-soft dimming curve. The
current PWM frequency is 582.
A flashing display indicates loss of DMX.
To use the control panel:
Use the Down and Up buttons to scroll between menu options.
Press the Enter button to select a setting, confirm a command or enter a submenu.
Press the Mode button to escape and return to the top of the menu.
