German Light Products®
impression FR10 Bar User Manual Rev. 20220727-1 17
Reset All
Performs a full fixture reset to initialize all features and effects.
Load Settings
Lets you load one of the customized Setting Presets from PRESET 1 to PRESET 3.
Loading the DEFAULT PRESET sets all fixture settings back to their default values. This
does not affect data network configuration settings such as DMX start address, IP
address etc.
Load Factory Backup
Important! The LOAD FACTORY BACKUP command will restore all factory default
settings including data network configuration settings such as DMX start address, IP
address settings, etc. This may mean that you lose communication with your controller.
The LOAD FACTORY BACKUP command does not change device counters and
calibration settings.
Main menus
The FR10 Bar has the following main control menus.
DMX Address
Sets the DMX start address of the fixture. The DMX address is 001 by default.
Control Mode
Selects one of the fixture’s DMX control modes. See ‘DMX control modes overview’ on
page 31.
Protocol Setup
Protocol Type
The fixture is compatible with DMX 512 and RDM control protocols. You can control the
fixture using DMX over a standard DMX cable link or over an Art-Net or sACN network:
• DMX (default setting) – The fixture uses the DMX control data received at its 5-pin
XLR connectors. No IP settings are required.
• Art-Net – The fixture uses the DMX control data received via Art-Net at its Ethernet
port. It is necessary to set up an Ethernet network. To configure the fixture to receive
control data via Art-Net, you need to set an IP Address, IP Subnet and Art-Net
port/universe (see Ethernet Config below).
Note that it is possible to transmit DMX data as broadcast or unicast packages via
Art-Net. If a large number of universes (more than 30) is broadcast, data loss can
occur. If you suspect that this is happening, configure your console to unicast Art-
Net DMX packages to fixtures or switch to sACN.
