12 Highlander Wash
User Manual
Figure 3. Control panel
Control panel
Warning! DMX control is disabled when the control menus are active. Be
prepared for the head to move as soon as you exit the control menus.
The control panel and backlit graphic LCD display with self-charging battery allow you
to change fixture settings, view readouts and use utilities quickly and intuitively, even
when the fixture is disconnected from power.
To allow comfortable use of the control panel, pan and tilt are automatically disabled
for a few seconds if you turn the yoke manually. Pressing any button on the control
panel also disables pan and tilt for a few seconds. Pan and tilt remain disabled for as
long you are working in the control panel. If no button is pressed for a few seconds,
head movement is re-enabled with pan and tilt correction applied.
Default screen
When power is applied, the fixture resets. After the reset has completed, the default
screen appears in the display. The fixture asks you to press any key to unlock the control
panel and display. When you unlock the display you will see this screen:
V:26/NS ECO
DMX
101
Shortcut Menu
See Figure 3. From left to right, the top line of the default screen displays:
● Main CPU software version
