www.glp.de DMX Mode 1: Basic
28 Fusion X-PAR 18Z User Manual
7. DMX control channel layout
In the following DMX channel layout tables:
● Where commands are marked with an asterisk * you must send that value
continuously for 3 seconds (or other duration if indicated in the table) to apply the
command.
DMX Mode 1: Basic
8 DMX Channels
Channel Command
DMX
range Percent
Default
DMX
Fade
1 Master Dimmer Intensity 0-100% 0-255 0-100% 0 Fade
2 Shutter
Closed 0-4 0-1.6% 255 Snap
Single Flash (when value changes) 5-9 1.9-3.5% Snap
Sync Ramp-Up (slowfast) 10-39 3.9-15.3% Fade
Sync Ramp-down (slowfast) 40-69 15.7-27% Fade
Sync Ramp up-down (slowfast) 70-99 27.4-38.9% Fade
Sync Double Flash (slowfast) 100-129 39.2-50.6% Fade
Random Strobe (slowfast) 130-359 51-62% Fade
Sync Strobe (1Hz-10Hz) 160-239 62.8-93.7% Fade
Open 251-255 98.4-100% Snap
3 Zoom Beam angle 6-43 degrees 0-255 0-100% 0 Fade
4 Control / Settings
No function 0-15 0-5.8% 0 Snap
Compatibility: Off* 16-20 6.2-7.8%
Compatibility: X-PAR 12Z 21-25 8.2-9.8%
Compatibility: X-PAR 8Z 26-30 10.1-11.7%
No function 31-35 12.2-13.7%
Color Mode: RGB HO (Calibrated)* 36-40 14.0-15.6%
Color Mode: RGB HQ (Calibrated)* 41-45 16.0-17.6%
Color Mode: RGBL * 46-50 18.0-19.6%
No function 51-55 20.0-21.6%
Dimmer speed smooth* 56-60 22.0-23.5%
Dimmer speed fast* 61-65 23.9-25.5%
No function 66-70 25.9-27.5%
Dimming curve Linear* 71-75 27.8-29.4%
Dimming curve Theatrical* 76-80 29.8-31.4%
