German Light Products® DMX control channel layout
Fusion XPAR 12Z User Manual Rev. A 35
Channel Command
DMX
range Percent
Defa
ult
DMX Fade
Zoom Reset* 176-180 69.0-70.5%
Fixture reset* 181-185 71.0-72.5%
Factory default settings
(except DMX address & mode)*
186-190 72.9-74.5%
No function 191-195 74.9-76.2%
PWM Rate: 600Hz 196-200 76.9-78.4%
PWM Rate: 1200Hz 201-205 78.8-80.4%
PWM Rate: 2200Hz 206-210 80.8-82.4%
PWM Rate: 3000Hz 211-215 82.7-84.3%
PWM Rate: 4800Hz 216-220 84.7-86.3%
PWM Rate: 9600Hz 221-225 86.7-88.2%
PWM Rate: 25KHz 226-230 88.6-90.2%
No function 231-252 90.6-100%
5 Red Intensity 0-100% 0-255 0-100% 0 Fade
6 Green Intensity 0-100% 0-255 0-100% 0 Fade
7 Blue Intensity 0-100% 0-255 0-100% 0 Fade
8 Lime Intensity 0-100% 0-255 0-100% 0 Fade
Note: Channel 8 has no effect unless Fixture Settings Æ Color Mode is set to RGBL
DMX Mode 2: Standard
11 DMX Channels
Channel Command
DMX
range Percent
Defa
ult
DMX Fade
1 Master Dimmer Intensity 0-100% 0-255 0-100% 0 Fade
Closed 0-4 0-1.6% Snap
Single Flash (when value changes) 5-9 1.9-3.5% Snap
Sync Ramp-Up (slowÆfast)
10-39 3.9-15.3% Fade
Sync Ramp-down (slowÆfast)
40-69 15.7-27% Fade
Sync Ramp up-down (slowÆfast)
70-99 27.4-38.9% Fade
Sync Double Flash (slowÆfast)
100-129 39.2-50.6% Fade
Random Strobe (slowÆfast)
130-359 51-62% Fade
Sync Strobe (1Hz-10Hz) 160-239 62.8-93.7% Fade
2 Shutter
Open 251-255 98.4-100%
255
Snap
3 Zoom Beam angle 6-43 degrees 0-255 0-100% 0 Fade
No function 0-35 0-13.7%
Color Mode: RGB HO (Calibrated)* 36-40 14.0-15.6%
Color Mode: RGB HQ (Calibrated)* 41-45 16.0-17.6%
Color Mode: RGBL* 46-50 18.0-19.6%
No function 51-55 20.0-21.6%
Dimmer speed smooth* 56-60 22.0-23.5%
Dimmer speed fast* 61-65 23.9-25.5%
No function 66-70 25.9-27.5%
Dimming curve Linear* 71-75 27.8-29.4%
Dimming curve Theatrical* 76-80 29.8-31.4%
Dimming curve Square Law* 81-85 31.8-33.3%
Dimming curve Inverse Square Law* 86-90 33.7-35.3%
No Function 91-95 35.7-37.3%
4 Control / Settings
No DMX = Hold scene* 96-100 37.6-39.2%
0 Snap
