www.glp.de DMX control modes overview
32 Fusion XPAR 12Z User Manual Rev. A
11. DMX control modes overview
The following DMX control modes are
available in the XPAR 12Z.
DMX Mode 1: Basic gives raw color
control using 8-bit RGB levels, with
overall dimmer and shutter controls.
The Lime channel has no effect unless
the fixture Color Mode is set to RGBL.
A Control / Settings channel lets you
configure the fixture remotely via DMX.
Mode 1
Basic
1 Dimmer
2 Shutter
3 Zoom
4 Control
5 Red
6 Green
7 Blue
8 Lime
DMX Mode 2: Standard provides a
selection of fixed colors with overall
dimmer and shutter controls. If Channel
9 is set below DMX 10 (3.9%) then the
color can be controlled by the RGB(L)
channels - the Lime channel has no
effect unless the fixture Color Mode is
set to RGBL. If Channel 9 is DMX 10 or
above, Channels 5-8 have no effect.
The CTC and M/G shift channels modify
the color selected by the other
channels.
A Control / Settings channel lets you
configure the fixture remotely via DMX.
Mode 2
Standard
1 Dimmer
2 Shutter
3 Zoom
4 Control
5 Red
6 Green
7 Blue
8 Lime
9 Color Wheel
10 CTC
11 M/G shift
DMX Mode 3: Advanced provides a
selection of fixed colors with overall 16-
bit dimmer and a shutter control. If
Channel 14 is set below DMX 10 (3.9%)
then the color can be controlled by the
16-bit RGB(L) channels - the Lime
channels have no effect unless the
fixture Color Mode is set to RGBL. If
Channel 14 is DMX 10 or above,
Channels 6-13 have no effect.
The CTC and M/G shift channels modify
the color selected by the other
channels.
A Control / Settings channel lets you
configure the fixture remotely via DMX.
Mode 3
Advanced
1 Dimmer
2 Dimmer Fine
3 Shutter
4 Zoom
5 Control
6 Red
7 Red fine
8 Green
9 Green fine
10 Blue
11 Blue fine
12 Lime
13 Lime fine
14 Color wheel
15 CTC
16 M/G shift
