German Light Products®Control menus and onboard display
Fusion XPAR 12Z User Manual Rev. A 27
9. Control menus and onboard display
Warning! DMX control is disabled when the control menus are active. Be
prepared for the fixture to emit strong light as soon as you exit the control menus.
The control panel and onboard OLED display provide access to user settings, readouts and
utilities.
Figure 9. Onboard control panel
The four control buttons have the following functions:
MODE/ESC: Activate the menus or go back one level towards the top of the menu.
UP: Scroll up or increase a number.
DOWN: Scroll down or reduce a number.
ENTER: Activate the control panel if it is in sleep mode. Then enter a menu, select a
setting or implement a command.
When you apply power to the fixture, it boots up. After it has booted, the panel displays the
default screen showing the fixture’s DMX mode and the DMX address that the fixture is
using.
In the default screen:
● Hold down the MODE button to show the Quick Set Menu.
● Hold down the UP or DOWN button to show the Settings Overview screen which lets you
see all main fixture information and settings. This can be useful if you are troubleshooting
or if you are in contact with GLP Service.
You can set the display to go into a blank sleep mode after a time by using the Display
Mode Æ Auto control panel option.
DMX control is disabled when the control menus are active.
See also the Display On / Off functions on the DMX Control / Settings channel.
