www.glp.de XPAR 12Z overview
12 Fusion XPAR 12Z User Manual Rev. A
3. XPAR 12Z overview
The Fusion XPAR 12Z from GLP is a powerful LED-based lighting fixture which uses a 120W
RGBL (red, green, blue and lime) LED emitter. A motorized Fresnel lens provides variable
zoom giving a beam angle from 6° – 44°.
The fixture can be controlled by DMX, or by settings on the control panel.
The XPAR 12Z can be used indoors in permanent and temporary installations. Its rugged
construction and IP65 rating mean that it can also be used outdoors in temporary
installations if precautions are taken to prevent immersion in water and damage from
direct sunlight. It can be fixed to any surface or suspended from a suitable structure as
described in Section 4.
T
he XPAR 12Z is not suitable for household use, for use in any location where unattended
children have access to it, or for use in permanent outdoor installations.
1
2
3
4
5
6
7
Figure 1. XPAR 12Z overview from rear
1 – Mounting bracket
2 – Adjustable foot
3 – Control panel with OLED display
4 – Power in and loop through connectors
5 – Vent for pressure equalization
6 – Safety cable attachment point
7 – DMX in and loop through connectors
