70 Fusion FS 16Z User Manual Rev. 20240625-01
Connections
AC mains power in and thru (out): Neutrik powerCON TRUE1 with sealing cap
Control data in and thru (out): Neutrik etherCON with sealing cap
Construction
Ingress protection rating: IP65
Fixture housing: Extruded aluminum
Color: Black
Thermal
Cooling: Convection
Minimum ambient temperature: -10° C (14° F)
Maximum ambient temperature: 40° C (104° F)
Max. total heat dissipation (calculated): 1130 BTU/hr.
Included items
Power cable with Neutrik powerCON TRUE1 mains input plug
2 x Adjustable Tilt Brackets
Glare shield
2 x Quick-release LockingPins
Dimensions and weight
Height including bracket: 231 mm / 9.09 ins.
Height without bracket: 181 mm / 7.12 ins.
Width: 90 mm / 3.54 ins.
Depth: 1020 mm / 40.28 ins.)
Weight: 13 kg (28.7 lbs.)
