46 Fusion FS 16Z User Manual Rev. 20240625-01
DMX Mode 3: Pixel 8-bit (79 channels)
provides a virtual color wheel (color
presets) and 16-bit RGBW color mixing.
A separate Shutter channel provides
strobe, pulse and ramp-up/down
effects and a 16-bit Master dimmer
channel controls overall intensity.
Zoom control is available, and the
fixture offers color temperature control
on a separate CTO channel.
This mode also offers individual pixel-
level RGBW color mixing.
A Control / Settings channel lets you
configure the fixture remotely via DMX.
Mode 3
Pixel 8-bit
1
Color wheel
2
Red
3
Red fine
4
Green
5
Green fine
6
Blue
7
Blue fine
8
White
9
White fine
10
Shutter
11
Master dimmer coarse
12
Master dimmer fine
13
Zoom
14
CTO
15
Pixel 1 Red
16
Pixel 1 Green
17
Pixel 1 Blue
18
Pixel 1 White
19
Pixel 2 Red
20
Pixel 2 Green
21
Pixel 2 Blue
22
Pixel 2 White
23
…
74
…
Pixels RGBW in sequence
…
75
Pixel 16 Red
76
Pixel 16 Green
77
Pixel 16 Blue
78
Pixel 16 White
79
Control / Settings
DMX Mode 4: Compressed RGBW
provides the main control options:
RGBW color mixing, zoom control and
a Control / Settings channel that lets
you configure the fixture via DMX.
Mode 4
Compressed RGBW
1
Red
2
Green
3
Blue
4
White
5
Zoom
6
Control / Settings
