Appendix → Spareparts
IV
Spareparts
#
article
code
description
amount
#
article
code
description
amount
1
200187
front plate
1
31
200335
Display mounting plate
1
2
200188
lens plate
20
32
200206
button mounting plate
1
3
200189
lens holder front
2
33
200204
silicone gasket for display
1
4
200191
lens holder back
2
34
200205
display cover
1
5
200190
lens 6°
20
35
200333
button silicone cover
1
6
200192
distance bolt front plate
8
36
200207
display pcb
1
7
200193
distance bolt lens holder
20
37
200213
mounting plate PSU & W-DMX
1
8
200327
IR PCB
1
38
200208
membrane
1
9
200328
distance bolt IR PCB
2
39
200210
powerCON TRUE1 Power-Out
1
10
200216
LED PCB
10
40
200209
chassis connector 5pin XLR female IP65
1
11
200217
housing / heatsink
1
41
200263
W-DMX Nano Transceiver
1*
12
200194
sealing for side plate
2
42
200334
distant bolt W-DMX mount
2*
13
200195
side plate
2
43
200264
W-DMX Support Bracket
1*
14
200196
distance bolt back plate
4
44
200265
W-DMX bracket for Antenna mounting
1*
15
200329
bracket for driver PCB mount
2
45
114200
Antenna Cable
1*
16
200214
bracket for driver PCB
10
46
114465
Antenna Cone IP65
1*
17
200212
driver PCB
10
18
200215
main PCB
1
A1
200220
Glare Shield
1
19
200211
Mounting Plate for Main PCB
1
A2
200260
ball lock pin
2
20
200197
cable guide PSU
4
A3
200252
Powercable TRUE1 - Schuko
1
21
200198
PSU
2
A4
20336
Standfoot with Tilt Function (Set of 2)
1
22
200199
terminal block
1
A5
200161
LED Fusion 2 RGBW 20x15W
1
23
200201
back plate
1
A6
200251
Diffusor filter Black Tube
1
24
200203
chassis connector 5pin XLR male IP65
1
A7
200271
Vertical Adapter Plate (w/o Omega Bracket)
1
25
200202
powerCON TRUE1 Power-In
1
A8
200272
Omega Bracket for Vertical Adapter
1
26
200330
plastic cover 1/4 Turn fast lock mount
4
A9
106599
Omega bracket
2
27
200331
1/4 Turn fast lock mount
4
A10
200174
Diffusion filter 40° for Fusion2
1
28
200332
sliding bracket mount
4
A10
200175
Diffusion filter 20° for Fusion2
1
29
200267
sliding bracket (set of 2)
2
A10
200176
Diffusion filter 60° for Fusion2
1
30
200200
mounting plate psu & terminal block
1
A10
200177
Diffusion filter 60x10° asym. for Fusion2
1
*only for W-DMX Upgrade!
