Appendix → Specifications
I
Appendix
Specifications
Light Source
• 20 x 15W Osram® RGBW LEDs
• LED Life Expectancy: approx. 20.000 hours
Optical System
• ConsistentColor™ Optics
• Beam angle 6°
Functions
• RGBW, 8 bit or 16 bit color mixing
• SteadyColor™ Dimming
• Seamless CTO
• Virtual color wheel with 39 colours including whites
(2.700 K, 3.200 K, 4.200 K, 5.600 K, 7.200 K and 8.000 K)
• all 20 LEDs controllable individually
• Pattern effects with variable speed and fade time
• High resolution dimmer 0–100%
• Selectable dimming curves
• Strobe with variable speed (max. 20 Hz)
• Pre-programmed random strobe & pulse effects
Thermal
• Maximum ambient temperature: 40 ° C (113 ° F)
• Convection cooled
Control and programming
• Setup and addressing via OLED display with 4 buttons
• Protocol: USITT DMX-512
• Control channels: 4, 6, 12, 17, 27, 32, 80, 92
• 8 DMX protocol modes
• Stand-alone mode
• Wireless DMX optional
• RDM
• DMX In/Out: XLR 5 pin (IP65)
• Power In/Out: Neutrik powerCON TRUE1
Electrical Specification
• Electronic auto-sensing switching power supply
• Input voltage: 100–240V AC, 50-60 Hz
• Max. power consumption: 330 W
Rigging
• 2 x Hole for M10 bolt
• 2 x Omega Bracket (optional accessory)
• Mount for safety wires
• 2 x stand with manual horizontal tilt
• Vertical Stand foot Adapter (optional accessory)
• Vertical hanging Adapter (optional accessory)
• Vertical Connection via quick-release pin
Mechanical Specification
• IP65 rating
• Height including bracket: 231 mm (9.09")
• Height without bracket: 181 mm (7.12")
• Width: 90 mm (3.54")
• Depth: 1006 mm (39.60")
• Weight: 12.5 kg (27.55 lbs)
Included accessories
• powerCON TRUE1® / Schuko Input cable
• Glare Shield
• Tilt Brackets with fast locks
• Quick Release Pins
Optional accessories
• Vertical Installation Adapter (hanging or standing) incl.
Omega Bracket
• Omega bracket (set of 2)
• Diffusion Filter (20° / 40° / 60° / asymmetric 10x60° /
Wall wash filter)
