www.glp.de Connecting to DMX data
20 Fusion MBL20 User Manual Rev. A
6. Connecting to DMX data
Check that all cables and connectors are suitable for the installation environment and
application (see recommendations in ‘Avoiding damage to the fixture’ on page 10).
Use digital 110 Ohm DMX cable with IP65 5-pin XLR connectors to supply DMX data to
fixtures.
Keep connectors sealed with their rubber caps at all times when not in use.
The MBL20 has two 5-pin XLR connectors for IN and THRU connections to a DMX data link.
MBL20 fixtures support the USITT DMX 512A signal protocol. They also support RDM (Remote
Device Management).
The 5-pin XLR connectors use standard pin allocations:
1
Signal Ground
2
Data –
3
Data +
4
Not used
5
Not used
If you would like advice with planning and installing a DMX link, your GLP supplier will be
happy to provide assistance.
