12 Fusion Exo Hybrid 40 User Manual
4. Control panel
Warning! DMX control is disabled when the control menus are active. Be
prepared for the head to move as soon as you exit the control menus.
The control panel and backlit graphic LCD display with self-charging battery allow you
to change fixture settings, view readouts and use utilities quickly and intuitively, even
when the fixture is disconnected from power.
To allow comfortable use of the control panel, tilt is automatically disabled for a few
seconds if you press any button on the control panel. Tilt remains disabled for as long
you are working in the control panel. If no button is pressed for a few seconds, head
movement is re-enabled with tilt correction applied.
Default information screen
When power is applied, the fixture performs a reset. After the reset has completed, the
default information screen appears in the control panel display on the side of the yoke.
At any other time, you can press any key to unlock the control panel. Doing this also
calls up the default information screen in the control panel display.
See Figure 3. The top line of the default information screen shows:
● DMX Mode
● LED Dimming PWM (top right)
● Input control source
STANDARD 3000HZ
DMX
001
Figure 3. Default information screen
