28 Fusion Creos Quick-Start and Safety Manual
DMX channel footprint: 15, 29, 69, 97, 133 depending on mode
Standalone operation: One captured scene
Setting and addressing: Onboard control panel with backlit graphic display, DMX,
RDM, iQ.Service app
NFC
FPO Port (Flexible Protocol Option) with LumenRadio CRMX Module
Firmware update: DMX Link via Dprog, GLP iQ.Mesh, Fixture2Fixture Push
DMX compliance: USITT DMX512
RDM compliance: ANSI/ESTA E1.20
RDM Manufacturer ID: 0x676C (GLP German Light Products GmbH)
RDM Device Model ID: 0x0067 (103 decimal)
Installation
Options: Standing on horizontal surface, mounted on rigging truss or pipe at any
angle
Rigging hardware attachment: Quarter-turn fastener points for two brackets
(supplied), each with 2 x quarter-turn fasteners
Operating position: Any
Minimum distance to combustible materials: 0.2 m (8 in.)
Minimum distance to illuminated surfaces: 1 m (3.3 ft.)
Installation environment: Temporary outdoor installation, temporary or permanent
indoor installation
Secondary attachment: 2 x safety cable attachment eyelets
Electrical
AC mains power: 100-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Maximum power consumption, all LEDs at 100% output: 800 W at 250 V
EU Energy Efficiency Class: B
EU Energy Efficiency Index: 0.87
Typical energy consumption: 677 W
Maximum permitted number of fixtures daisy-chained to power
2 x Fusion Creos total @ 100-120 V, 60 Hz
5 x Fusion Creos total @ 200-240 V, 50 Hz
Connections
AC mains power IN and THRU: powerCON TRUE1
Standard DMX data link IN and THRU: 5-pin XLR
Art-Net/sACN data link IN and THRU: etherCON, failsafe link integrity
Construction
Ingress protection rating: IP65
Fixture housing: High-impact flame-resistant thermoplastic, aluminum alloy, steel
Color: Black
Tilt lock
Foldable base handles
Thermal
Cooling: Fan cooling with 5 fan modes – Regulated, High, Medium, Low, Minimum
