German Light Products® DoP Converter DINrail / UM
GLP DoP Converter User Manual Rev. 20220320-01 11
5. Installation
Warning! Read ‘Safety’ starting on page 4 for important safety information
that you must understand before you install or operate a GLP DoP system.
Install DoP Converters only as described in this chapter, or you may create
an installation that is unsafe.
The safety of the installation is the responsibility of the installer. If in any
doubt about safety, consult an expert or contact your GLP supplier for
advice.
Installation and system limitations
The DoP system uses a high-frequency signal that can interfere with any other systems
that use the same frequency band to send a data signal over mains power circuits.
Note that the DoP data is freely transmitted over the power network within the
transmission range of the DoP Converter.
If you need to prevent the transmission of DoP data over the mains power
infrastructure, we recommend that you install line filters that block the DoP signal at the
appropriate system endpoints.
When installing DoP systems, observe the following safety limits and recommendations:
Description
Limits
Mains power input/output
Minimum 85 VAC nominal,
47/63 Hz
Maximum 305 VAC nominal, 47/63 Hz
Mains current safety limit
Maximum permitted current flow through
the DoP Converter = 16 A.
Operating temperature range
Minimum -20° C (-4°F)
Maximum 70° C (158°F)
Recommended DMX cable type
DMX cable, 2 x 0.34 mm²
Cat 5e/7 cable, 27 AWG
Maximum number of devices on one
DMX link
32 devices
Maximum number of devices on one
mains power line
Theoretically 128 devices
Recommended maximum 32 devices
Maximum DMX cable length between
two devices
100 m / 328 ft. (DMX cable, 2 x 0.34 mm²)
125 m / 410 ft. (Cat 5e/7 cable, 27 AWG)
