German Light Products® GLP ArenaLED1 Touring
Rev. 20241104-01 25
images. You can adjust the PWM frequency using either the Control/Settings DMX
channel or RDM.
The following PWM settings are available:
• Low - PWM is fixed at a lower frequency, giving good results when dimming.
• Optimum (default setting) - PWM is set to a frequency which offers best results
in dimming.
• High1 - PWM set to a higher frequency.
• High2 - PWM set to a higher frequency than High1.
• Max - PWM frequency is set to the highest possible level. Use this setting for
slow motion video or high speed camera applications. Dimming resolution is
lower than at all the other PWM settings.
No Signal
NB: No Signal functionality is not fully implemented in firmware v.0.5.0.
Some functions may be absent or may not work.
Sets what the fixture should do if no DMX signal is present (if the fixture is being
controlled by DMX but the DMX signal stops, or if you apply power to the fixture
when no DMX signal is present):
• Blackout - The fixture blacks out whenever it is not receiving a DMX signal.
• Emergency Scene –The fixture switches to medium-level utility lighting (so that
an audience is not left in total darkness, for example).
• Standalone Scene – The fixture plays its stored stand-alone scene. This is either
the last scene that was set via DMX or the scene that has been captured and
stored (see Capture DMX Values below). If no stand-alone scene is stored in
memory, the fixture plays the default scene which is “black out”.
• Capture DMX Values - Takes a snapshot of the DMX values that are currently
being received and stores them in the fixture’s memory as its standalone scene.
The fixture will display this scene if it is set to Standalone Scene (See Standalone
Scene above).
Power Mode
NB: Boost Mode is not implemented in firmware v.0.5.0. The fixture operates
in Normal Mode only.
Lets you boost LED output for a short time and then regulate it down to normal.
This feature gives a very dynamic performance, especially for show and effect
lighting.
• Normal – Runs the fixture with standard RGBL-White output for continuous
output level without automatic self-dimming.
• Boost – Pushes the fixture’s maximum output for punchy short-duration flashes
with automatic self-dimming to control fixture temperature.
