KNIFE SHARPENING
Occasional touching up along the edges of knife with a honing stone will keep cutting operations at peak
performance.
PUSHER PLATE STOP
Frequently check that the pusher plate does not hit grater plate holder or knife shaft assembly. The
pusher plate stop screw can be adjusted to avoid touching the internal moving parts. With proper
care and maintenance, your Vegetable Grater/Shredder/Slicer Attachment will provide many years of
performance.
XP1024 Brass
XP1023
XP1022 Plastic
XP1014
XP1026A
XP1026 Brass
XP1030
XP571
(Knife only)
XP1004
XP1005A
XP1005
XP1007
XP1009
XP1011
XP1008
XP1010
Housing
XPH Plate Holder
XASP Adjustable Slicer Plate Assembly
XVSH Housing
XP1018
XP1017
XP1036
XP1035
XP1012
XP1013
XVSP
Pusher Plate
XVSD
Plate
XVSD Hopper
6.When using the adjustable slicer plate,
make sure it is cleaned frequently to assure
easy thickness adjustment. Occasionally
disassemble the adjustable slicer plate for a
thorough cleaning. To do this it is necessary
to unscrew knurled thrust bearing, which
has a left hand thread, to release the spring.
Remove knife and shaft assembly. Unscrew
adjustment nut from adjustable slicer plate.
Use a drop of approved food machinery
oil on shaft and adjustment threads after
cleaning.
Thrust
Bearing
Spring
Adjustment
Nut
CAUTION: Do not allow water or moisture to remain on or in hub, shaft, or rear opening in
the housing. This condition will result in rusting which after some time can destroy the rear end
components and shaft and void the 1 year factory warranty.
Note: To prevent damage after cleaning thrust bearing must be tightened until sealed against
shoulder on shaft. Failure to properly reassemble can result in damage to knives, shaft and
adjustable slicer plate. Do not clean components in dishwasher with strong detergents or
chemicals. Use a USDA approved grease on shaft for best operation.
XP571 (Knife and Shaft)
