6
INSTALLATION OF ANTI TILT BRACKET
Install the legs to the cooker and adjust the height to the desired level. Make sure that
this height is absolutely correct to what you require.
On the rear of the cooker there is a covering panel. Accurately measure the distance
from the top of this panel to the floor Height H.
Mark the same height on the wall against which the cooker is to be installed.
Mark the centre of the cooker at the same height on the wall.
At a distance of 150mm either side of the centre at the measured height mount the
2 anti tilt brackets supplied onto the wall.
Slide the cooker into position after connecting the chain. The brackets prevent any
chance of the cooker tilting forward.
150mm
Connect safety
chain onto wall
with hook
Rear cover
Brackets mounted
onto wall and cooker
slides underneath
Rear view showing brackets attached to wall
H
H
Slide cooker
under brackets
Side view showing brackets attached to wall
