- Burners with electric ignition
¾ Models with ignition button
To switch on one of the burners, press the ignition button and turn the knob to the maximum flow button
(
symbol). Hold the ignition button down until it lights and then adjust the flame by turning the knob until the
desired flame is obtained.
¾ Models with ignition incorporated into the knob
These models are identified with the
symbol near to the symbol (maximum flow).
To light one or more burners, press and turn the knob to maximum flow and hold it down until the bunrers are lit;
turn the knob until the desired flame is obtained.
Note:
If it is difficult to light the burner with the knob in the maximum position because of local gas flow, we
recommend repeating the operation with the knob on minimum before placing a vessel on the ring.
- Burners with safety valves
Some models have safety valves which automatically interrupts gas flow should the burner switch itself off for
any reason.
Turn the knob to the
and repeat the lighting operations explained in the following paragraphs to restore
functionality.
¾ Using the burner
According to the type of electric ignition, proceed as follows:
) For models with ignition incorporated in the knob, turn the gas valve knob to maximum flow and then press
and hold it down for about 4 to 5 seconds. Release the knob and adjust he flame by turning the knob until it
reaches the desired intensity.
)
Warning
:
The ignition device cannot be activated for more than 15 seconds.
If it still has not lit after this time or it turned off accidentally, wait for 1 minute before repeating the
operation.
)
For models with ignition button, turn the gas valve knob to maximum flow and then press the ignition button
and hold it down for about 4 to 5 seconds. Release the knob and adjust he flame by turning the knob until it
reaches the desired intensity.
Using the ring
Hob grids were designed to make the product easy and safe to use. We recommend checking their exact
position and stability on the hob before each use. Furthermore, check that the supporting rubbers are integral
and correctly positioned.
Gird for small vessels (
Fig. 39)
Only use the auxiliary burner ring (the smallest) for vessels with a small diameter to prevent them for tipping.
Special ring for WOKs (Fig. 40 optional)
Only use the triple crown ring for WOKs (concave bases). In order to avoid serious burner malfunction, we
recommend not using woks without this special ring and not to use it for flat-based pans
Choosing the burner
The symbology printed on the panel (diagram fig. 41) to the side of the knob indicated the correspondence
between the knob and the burner. Choosing the most adapt burner depends on the vessels’ diameter and
capacity (see table).
It is important that the pan’s diameter is adequate to the burner power not to compromise high yield.
5
Appliances with safety valve
Flame supervision device
Device which, under the influence of the flame on the detector element, holds open a supply of gas to the burner
and which shuts off least this supply of gas in the event of extinction of the supervised flame.
¾
