15
Install the Horizontal Bike Hook
■ When not in use, bike hook may be rotated to the side so it lies
at against the bracket.
1. Engage the bracket rims on the horizontal bike hook into the
slots in the GearWall
®
panel or GearTrack
®
channel by lifting
up, pushing toward the wall and lowering the rims into the
slots.
2. Inspect the bracket from the side to ensure the
rims are fully engaged in the slots as shown.
Install the Storage Bin Holder
■ Designed to be used as a pair, the bin holders will support one
storage bin up to a maximum 18 gallon size.
1. Measure the length of the storage bin 4" (10.2 cm) to
5" (12.7 cm) from the bottom.
2. Install the storage bin holders into the slots in the GearWall
®
panel or GearTrack
®
channel so that distance between the top
of the holders is the same as the length of the storage bin.
NOTE: Engage the bracket rims into the slots by lifting up,
pushing toward the wall and lowering the rims into the slots.
3. Inspect the bracket from the side to ensure the
rims are fully engaged in the slots as shown.
4. Set the storage bin into the bin holders so that the bottom
and sides are supported by the storage bin holders.
Horizontal Bike Hook
Storage Bin Holder
WARRANTY
For warranty information:
In the U.S.A. call 1-866-342-4089 or visit our website at
www.gladiatorgarageworks.com
In Canada call 1-800-807-6777 or visit our website at
www.gladiatorgarageworks.ca
