13
- With the keys “Max” e “Min“it is possible to bring power of hob to maximum or minimum.
- Using the keys "+" and "-" it is possible to change the power and thus the amount of heat transmitted.
Power can be set on: 200, 400, 600, 800, 1000. 1200, 1400, 1600, 1800, 2000W.
- After cooking, push the ON / OFF button, to turn off the appliance. Display shows “Lo”
1A) Timer after power regulation
- Press “Select” during cooking. The red light “time” flickers, and display shows “0”.
- With the keys “+” e “-“ set the duration of cooking, up to 180 minutes.
- Display will show for some seconds the time set.
- During cooking on the display will appear the power selected, and the time set.
- Cooking will stop automatically when time finishes.
2) Cooking with temperature regulation
- Press “Select” 3 times, until the red light on “Temp” switches on, and display shows “180”.
- With the keys “+” e “-“ select desired temperature. There are 10 selectable levels, from 60° to 240°C.
2A) Timer after temperature regulation
- Press “Select” a 4
th
time. The red light “time” flickers, and display shows “0”.
- With the keys “+” e “-“ set the duration of cooking, up to 180 minutes.
- Display will show for some seconds the time set.
- During cooking on the display will appear the power selected, and the time set.
- Cooking will stop automatically when time finishes.
KEY LOCK To lock the keypad on the control panel (4) press together the keys “+” e “-“ during use.
On display will appear L to indicate the lock. To unlock press together the keys “+” e “-“.
SAFETY DEVICE
The unit turns off automatically if there is any pan placed on it, or it is removed, or it is made of such a
material not suitable for induction cooking.
In this case, the unit will show E0 for about 30 seconds, and then goes into stand-by mode, showing “Lo”.
Every time you turn off the appliance by pressing the ON / OFF button, the fan will continue to run for
approximately 60 seconds to cool down any part of the unit. To turn off the product, always push the ON /
OFF button, do not turn it off by removing the cooking container.
ERROR MESSAGE
Error
Cause
Solution
E0
Not suitable vessel.
Vessel is not placed inside the
cooking area.
No vessel.
Use only pans suitable with induction cooking.
Place the vessel on the cooking area.
E01
Internal overheating or short
circuit.
Check the ventilation fan is not obstructed, refer to an
Authorized Service since the thermostat could be defective.
E02
Crystal plate is overheating.
Let the plate cool down for a few seconds. Restart operation
only when the plate is cool.
E03
High or low Voltage
Plug on a suitable electrical power outlet.
CLEANING - Unplug the unit from the electrical power outlet and wait for the complete cooling
down of every parts before starting cleaning.
Do not immerse in water and never leave the appliance under the jet of tap water. In any case, prevent water
or other liquids to flow on the surfaces. Do not use abrasive or metal sponges for cleaning.
Clean the cooking plate with a damp sponge.
