-Comfort
middle section and unfold the canopy. To
access the ventilation window, simply lift
the ventilation cover.
HOW TO FOLD UP THE FRAME
(WITHOUT THE SEAT UNIT)
Ensure the storage basket is empty.
16. Press the buttons on both sides and lift the
plastic part, then remove your hand and
the stroller will fold automatically until the
locking mechanism of the stroller is secured
in place.
HOW TO FOLD UP
THE FRAME WITH THE SEAT
Note: The stroller can be folded with the seat
unit assembled facing either side.
• Unlock the front wheels
• Handle in the lowest position
• Push down the back of the basket
• Ensure the storage basket is empty
• Unlock the front wheels
17. With the seat unit facing forward, fold the
seat forward, push the seat backward and the
stroller will fold automatically.
18. With the seat unit facing backward, fold
the seat backward and the stroller will fold
automatically.
HOW TO USE
THE PARKING BRAKE
19. Press the brake pedal with your foot to lock
the rear wheels. Lift the brake pedal with your
foot to unlock the rear wheels.
HOW TO LOCK
THE FRONT SWIVEL WHEELS
20. Rotate the locking mechanism from both
sides to the middle to lock the front swivel
wheels. Rotate the locking mechanism from
the middle to both sides to unlock the front
swivel wheels.
CARRYCOT
HOW TO USE THE CARRYCOT (IF PRESENT)
WARNING: The carrycot can only face
backward! Do not fold or unfold the carrycot
when your child is in it. Make sure that the
carrycot is properly fitted into the frame of
the stroller before pushing it.
ASSEMBLY
21. Open the canopy until you hear a ‘click’
sound, then hold the handle and apply
downward force to open the carrycot, then
attach the carrycot to the frame.
FOLDING
(IF YOU HAVE THIS FUNCTION)
22. To fold the carrycot, press and hold the
buttons underneath the carrycot.
HOW TO FIX THE CARRYCOT
23. Place the carrycot over the stroller and press
the two plastic sides firmly into the joint of
the frame until you hear a ‘click’ sound.
REMOVING THE CARRYCOT
24. Press the button on the handle and lift the
carrycot off the frame at the same time.
CLOSING THE CANOPY
25. Press the buttons on both sides simulta
-
neously, then push the canopy down.
EXTENDING THE CANOPY
26. Unzip the middle section, press the buttons
and hold the top section to extend the
canopy.
ACCESS TO THE VENTILATION WINDOW
27. Open the zip as shown to open the ventilation
window.
HOW TO USE THE CAR SEAT ADAPTER
(IF PRESENT)
28. Insert the car seat adapters in chassis.
A ‘click’ sound indicates that the car seat is
properly fixed.
29. Insert the car seat in the car seat adapter.
30. Press the buttons in the car seat to remove
the car seat.
31. Press the buttons to remove the car seat
adaptors.
HOW TO USE THE SAFETY HARNESS
32. Press the left side of the buckle button to
release the left waist belt.
33. Follow the same procedure for the right
waist belt.
34. ‘D’ rings are included for an additional
harness if desired.
