UK
Giordani -3 Matic
INSTALLATION
1. Unzip the carry bag and open the three Velcro belts to
unfold the mattress and take out the travel cot.
2. Insert the four universal wheel shafts vertically into
the foot holes on the bed.
3. Place the travel cot vertically on a level floor, pulling
the travel cot legs slightly apart.
4. Press down the centre of the cot base until it is flush
with the flat surface of the floor to lock it in place.
Note: Aer stretching it out, gently press the four side
armrests to check that they are locked in place.
INSTALLATION OF THE MATTRESS
5. Attach the tubes to the mattress.
6-1. Use the mattress in the bassinet.
Place the mattress in the top second layer with the
softer side up.
6-2. Use the mattress in the bottom layer of the travel cot.
Open the Velcro cover, unfasten the buckle and then
unzip and remove the bassinet (second layer).
Place the mattress in the travel cot with the soer side up.
Secure the mattress to the base of the travel cot: li each
end of the mattress to insert two hook-and-loop straps
through the button-hole openings in the base of the travel
cot and fasten underneath. Repeat for the opposite end.
IMPORTANT: Gently lift the mattress to ensure it is
attached.
FOLDING STEPS
7. Remove the mattress, grasp the safety lock rope in
the middle of the bed and lift it more than halfway
up the bed.
8. Move the railings towards the centre.
9. Stack the bed and accessories on one of the bed boards
at the front of the mattress, then tighten them with
Velcro. Put the cot in the bag and carry it lightly.
BEDSIDE FUNCTION
10. Undo the Velcro and open the two zips on the two sides
of the lowering rail (10A).
Undo the zip between the lowering rail and the
bassinet (10B).
11. Locate the buttons next to the plastic corners on the
le and right and push them outwards to unlock (11A).
Slide the top bar down until it reaches the bottom
(11B).
Remove the mattress and zip up the zip between the
lowering rail and the base of the bassinet. Put the
mattress back in (11C).
Note: The left and right plastic corner pieces must be
slid down at the same time, so that the top rail can
be lowered smoothly.
BEDSIDE HEIGHT ADJUSTMENT
12. Check the height of the travel cot in relation to the
mattress of the adult bed.
WARNING! When used in bedside mode, the top edge
of the lowering rail must be level with or below the top
of the adult mattress.
To attach the travel cot to the adult bed, use the connec
-
tion belt supplied (G). Connect each male buckle on the
connection belt to the female buckle on the rear legs of
the travel cot.
A “click” will signal when secure.
When used in cot mode, the zip of the bedside must be
closed.
13. Move the travel cot close to the adult bed, pass the
connection belt under the adult mattress and place
the anchor plate flush between the adult mattress
and the base.
WARNING: NEVER use the product in ‘co-sleeper mode’
without the connection belt attached to the adult bed.
Failure to use this connection belt could result in seri
-
ous or fatal injury to the child.
Make sure that the connection belt is secure and tight.
Check the belt before each use.
WARNING: Failure to use this restraint system will al
-
low the product to move away from the adult bed and
could result in the child falling out of the product.
WARNING! NEVER leave a child unattended in this
product.
Tighten the belt, ensuring there is no gap between the
adult bed and the mattress. If the gap exceeds 13 mm,
readjust the connection belt and pull it tighter.
CARE AND MAINTENANCE
Check your travel cot from time to time for worn parts, torn
fabric or stitching. Replace or repair the parts as needed.
If the travel cot is used at the beach, you MUST remove sand
from the travel cot, as sand can damage all moving parts and
locks on the travel cot.
The travel cot, mattress and bassinet are surface wash only.
Use only household soap or detergent and cold water. To
wash the travel bag, machine wash in cold water on a delicate
fabrics cycle and then drip dry.
DO NOT USE BLEACH.
17
