Model: GVHC & FParts List
Item Part No. Qty. Description
1 95703 1 FILTER ACCESS DOOR ASSEMBLY (COMPLETE)
2 41257 1 LATCH, COMPRESSION (INCLUDED WITH DOOR)
3 21441 1 SWITCH, ROCKER, (ON)0NOFF, 250V, 20A
4 94322 1 AIR DIVERTER
5* 41115 1 DAMPER, FIRE, 10 X 10, SHALLOW
6* 93296 1 BLOWER ASSEMBLY, GVH HOOD
7 21157 1 SWITCH, LIMIT, 15A, 250V
8 24209 1 L.E.D. CLUSTER, EAC FILTER
9 20399 1 INDICATOR LIGHT, AMBER, 250V, 0.5W
10 20398 1 INDICATOR LIGHT, GREEN, 250V, 0.5W
11 20402 2 INDICATOR LIGHT, RED, 250V, 0.5W
12 20572R 1 EAC CLEANING TIMER BOARD, REPLACEMENT
13 21203 1 RELAY, NO, 240V
14 20694 1 PILOT LIGHT, YELLOW, EAC CLEANING TIMER
15 20693 1 PILOT LIGHT, RED, EAC CLEANING TIMER
16 20692 1 SWITCH, MOMENTARY PUSHBUTTON, EAC CLEANING TIMER
* Hidden
7.04 Parts List for Hood Front / Control Panel
