Model: GVHC & FParts List
* CE Version
7.02 Parts List for Rear Electrical Components
Item Part No. Qty. Description
1 21296 1 EAC POWER PACK/DRIVER BRD, 120V
2 23776 1 ALARM & SHUTDOWN MODULE, AIR FILTER
3 21510 1 DIST.BLOCK, 12PL, 1226 AWG, BLACK
4 21509 1 DIST.BLOCK, 12PL, 1226 AWG, RED
5 21496 4 END BRACKET CLIP, DIN RAIL, PTFIX, NS35
6 94784 1 RAIL, DIN, 3IN
7 23782 1 SONALERT, CONTINUOUS TONE, 250V
8 22950 1 SONALERT, 250V, INTERMITTENT
9 20473 1 SWITCH, VACUUM, DUNGS, 0.4 > 4.0 WC
10 21151 1 CONTACTOR, 63AMP, 3PH, 208/240V
11 20411 2 FUSE HOLDER, DIN RAIL, 600V, 35A
12 21875 2 FUSE, 6AMP, SC6
13 20312 1 BASE, RELAY, PLUGIN, DIN MOUNT
14 20318 1 RELAY, 240 VAC, 10A, ELECTROMECH
15 20320 1 TERMINAL BLOCK, GROUND, AWG 824
16 20319 5 TERMINAL BLOCK, 50 AMP, AWG 824
17 20303 8 / 6* TERMINAL BLOCK, 412 GA WIRE
18 20304 2 TERMINAL BLOCK, GROUND, 412 GA WIRE
19 24237 2 SWITCH, PLUNGER, 250V, 15A
20
*
20397 1 LINE FILTER, INCOMING POWER, 10A
21 21337 1 TRANSFORMER, 230VAC >115VAC @.86A (Includes mounting hardware)
22 93134 1 DIN RAIL, 11.0”
23 40550 4 PLASTIC BUSHING, 11/4”
24 40880 1 NYLON FITTING, 90EL, 1/4” BARB, 1/4NPT
25 40877 1 NYLON FITTING, 90EL, 1/4” BARB, 1/8NPT
26 21125 1 E.A.C. CONTACT BOARD
