Model: GVHC & FOverview
3.02 Hood Front & Filter Chamber
Item Description Function
1 Filter Access Door
Provides access to all hood filters (baffle, EAC cell & charcoal).
Hood will not operate unless door is closed and latched properly.
2 Double Baffle Filter
First stage of the air cleaning system. Highefficiency doublesided
baffle filter. Easily removed & hinged for easy daily cleaning.
3 E.A.C. Collector Cell
Cell electrostatically captures and removes very fine grease vapor
particulate and smoke generated during cooking. Preferably, the
cell must
be cleaned daily to maintain hood performance.
4 Charcoal Filter
Activated charcoal helps to control cooking aromas in the
recirculated air. Typically, filter requires monthly replacement. Must
be replaced with new fresh filter ... NEVER attempt to clean and re
use.
5
Exhaust Outlet
w/Diverter
Outlet atop of the unit directs cleaned air back into the space, to
the sides and rear. [0”] clearance is required between top of
diverter and ceiling or overhead obstructions. Some clearance is
preferable to make future movement the unit easier, if needed
.
6
+
Grease Drip Cup
Collects grease condensate generated by the baffle filter. Cup
should be routinely checked, emptied and cleaned as needed.
7*
Appliance Receptacle
(Optional)
Interlocked appliance power receptacle (NEMA), 50A max. Plug
appliance power cord directly into hood ... can possibly eliminate
need for a separate appliance power supply.
8
+
UnderHood Light
Fluorescent lighting illuminates the appliance area under the
hood.
* Optional
+
Not Seen
