10
Model: GVHC & F Installation
2.04.2 GVH‐F Floor‐Stand Hood
HOOD APPROVED FOR ELECTRICALLY HEATED APPLIANCES ONLY.
B
MIN.
C
MAX.
HEATING
AREA
A
MIN.
HEATING
AREA
29 5/8 INSIDE
32 1/4 INSIDE
D
MAX
APPLIANCE RESTRICTIONS
APPLIANCE A B C D MAX. AMP.
MAX. SURFACE
AREA
MAX. SHORTENING
CAPACITY
MAX.
TEMP
MAX
ELEMENTS
FRYER(S) 5/16 8 N/A 19
100 TOTAL* (MAX 50AMP
THROUGH HOOD
INTERLOCK CONTACTOR)
576 SQ. IN.
0LBS/ GAL
N/A
GRIDDLE 2-11/16 8-3/4 19 N/A 35 480 SQ. IN. N/A 450F N/A
RANGE 2-7/8 8-3/4 19 N/A 44 TOTAL ALL BURNERS N/A N/A N/A 4
OVEN 1 8-3/4 19 N/A
55 TOTAL* (MAX 50AMP
THROUGH HOOD
INTERLOCK CONTACTOR)
N/A N/A 500F N/A
CONVEYOR
OVEN
5-1/2 8 19 N/A
55 TOTAL* (MAX 50AMP
THROUGH HOOD
INTERLOCK CONTACTOR)
N/A N/A 500F N/A
TOASTER 1 8-3/4 19 N/A
55 TOTAL* (MAX 50AMP
THROUGH HOOD
INTERLOCK CONTACTOR)
N/A N/A 500F N/A
A
MIN.
* Appliance(s) exceeding 50A must be powered through a circuit separate from the hood and be interlocked
through the hood’s contactor coil.
