27
GGF Series Gas Fryer
Overview
Item Description Function
*1 Crumb Catcher Screen
*OPTIONAL, SOLD SEPARATELY, NOT INCLUDED
Designed to catch large crumbs, cooking offal & residue as oil drains into
the Filter Pan.
2 HoldDown Frame
Secures filter media tightly against Filter Pan bottom to provide a good
pump suction seal. Improper placement will likely affect Filter Pump
performance.
3 Filter Paper
Standard, disposable paper filter media. Filters fine sediment & residue
from cooking oil during the filtering cycle.
4 HoldDown Levers [4}
Secures hold‐down frame firmly against the filter media in filter pan. If
levers are not properly engaged, there is potential for poor filter pump
performance.
5 Filter Pan Hose
Connects the filter pan to the fryer’s oil filtration system. This hose must be
disconnected before the filter pan can be removed.
6 Filter Pan
Collects used cooking oil for filtering; contains filter media which filters &
reconditions oil during the filter cycle. The filter pan features casters ... it is
easily removed for cleaning & refreshing filter media. Features a
permanently attached perforated media support screen ... will help prevent
large particle residue from entering the filter system should media be
accidentally damaged. THIS IS NOT A SUBSTITUTE FOR FILTER MEDIA ...
MEDIA MUST BE USED!
*7
Stainless Steel
Wovenwire Mesh Filter
Screen
*OPTIONAL, SOLD SEPARATELY, NOT INCLUDED
A cleanable, sustainable, reuseable filter screen used as a direct substitute
for standard paper media. Durable, can be used many times.
* Nonstandard; Sold separately; Not Included
3.3. Filter Pan Assembly
