25
GGF Series Gas Fryer
Overview
Item Description Function
1 Diverter Valve Handle
Directs filter pump discharge to either the fry pot or to the Waste Oil
Discharge Hose.
2
Quick Coupling Oil
Discharge Hose
Connects the Waste Oil Discharge Hose to fryer plumbing when removing
waste oil from fryer.
3 Drain Valve Handle
Operates the fry pot DRAIN VALVE. Always be sure that valve is closed
prior to adding cooking oil or water for boilout. As a safety precaution,
the burners will not ignite if valve is not completely CLOSED.
4
Quick Coupling Filter Pan
Hose
Connects the Filter Pan Assembly to the fryer’s onboard oil filtration
system.
5 Filter Pan Assembly
Collects oil when drained from pot. Contains filter media for filtering &
reconditioning cooking oil after use.
6 Filter Pan Cover
Helps minimize splash when hot oil is drained into the filter pan and helps
safeguard against contamination of oil during the filtering process. Sits
loosely atop filter pan & is easily removed for cleaning.
7 Cabinet Door
Provides access to lower fryer cabinet & filter pan. If needed, swing of the
door is field reversible.
8 Door Magnet Keeps door closed during operation
3.2. Lower Cabinet
