23
GGF Series Gas Fryer
Overview
3.1. Control Panel
Item Description Function
1 POWER Switch
Turns fryer power ON/OFF. Press top portion to place in [ON] position for
operation.
2 SELECTOR Switch
3position switch selects fryer mode ... [COOK OFF FILTER PUMP].
Burners will only ignite & operate when in [COOK] position. Place in [FILTER
PUMP] position to run filter pump. Centered position is [OFF].
3 Computer Controller
Computer controller regulates cooking oil temperature & cooking time.
Stores up to fifty (50), programmable menu item cooking presets.
Continuously monitors fryer operation, displays alarm & error conditions and
shows operational instruction prompts.
Keypad used for inputting values & settings
Function keys used to beginning specific controller functions.
4 POWER Light Green light is ON whenever the POWER switch is in the [ON] position.
5 HEAT Light
Amber light illuminates when burners are ON. When setpoint temperature
is reached, the light turns OFF. Light cycles ON & OFF during normal
operation as controller maintains oil temp.
6 HILIMIT Light
Red highlimit light illuminates when the overheat safety thermostat turns
OFF power to gas valve, stopping flow to burners. Should this light come
on, discontinue operation & refer to the Troubleshooting Section. NEVER
COOK IN A FRYER THAT CONTINUES TO GIVE A HI‐LIMIT ALARM!
7 FLAME FAIL Light
The red FLAME FAIL light illuminates whenever burner control system
detects that there is not a flame present at the burner & the gas control
valve has shutdown gas flow.
