53
7.04 Parts List for Hood Component Box Assembly
Parts List Free Standing Ventless Hood
FSH-2 & FSH-2A-99
Item Part No. Qty. Description
1 20303
6 TERMINAL BLOCK, 164 AWG, 600V, 85A (ONLY 3 w/RECEPTACLE OPTION)
+2 (CE MODEL ONLY, NEUTRAL)
2 20304 2 TERMINAL BLOCK, GROUND, 164 AWG
3 20319 4 TERMINAL BLOCK, 248 AWG, 600V, 50A
4 20320 1 TERMINAL BLOCK, GROUND, 248 AWG
5 20312 1 BASE, RELAY, PLUGIN, DIN MOUNT
6 20318 1 RELAY, 240 VAC, 10A, ELECTROMECH
7 97371 1 RAIL, 8.375, DIN3
*8 21337 1 TRANSFORMER, 230VAC >115VAC @ 0.86A
9 21509 1 DISTRIBUTION BLOCK, 12PL, 1226 AWG, RED
10 21510 1 DISTRIBUTION BLOCK, 12PL, 1226 AWG, BLACK
11 21496 4 CLIP, DIN RAIL, END BRACKET, PTFIX, NS35
12 94784 2 DIN RAIL, 3”
13 23776 1 ALARM & SHUTDOWN BOARD, AIR FILTER
14 22950 1 SONALERT, INTERMITTENT TONE, 250V
15 23782 1 SONALERT, CONSTANT TONE, 250V
*16 20411 2 FUSE HOLDER, DIN MOUNT, 690V, 32A
*17 21693 2 FUSE, 15A, CC, 1.5”
18 21296 1 POWER PACK, 120V, W/ DRIVER BRD & JUMPERS
19 20442 1 POWER LINE FILTER, 10A, 10kHz30kHz (CE VERSION ONLY)
20 21245 1 CONTACTOR, 60A RES, 3PL, 100250V COIL
* Not shown
NOTE:
HEPA Filter version does no include Items 8, 13, 14, 18.
