5.03.1 Monthly Hood Interlock Inspection (Generally Performed by User)
Free Standing Ventless Hood
FSH-2 & FSH-2A-99
Cleaning &
Maintenance
5.04 Fire Suppression System Maintenance
Hood design incorporates various interlock switches to ensure that the unit will shutdown if certain conditions exist which
are not consistent with safe & effective operation. The interlocks should be inspected & tested MONTHLY as described
below. Use the Maintenance & Service Log to record completion of testing. If problems are detected, contact GILES or
an authorized service company.
1. Door Interlock Test: Start hood. With hood running, unlatch & slightly lift the bottom lip of the filter access
cover to confirm that hood powers OFF when cover is lifted & the fryer under the hood turns OFF, or cannot
be turned ON.
2. Baffle Filter Test: Remove baffle filter then turn ON hood power. Verify that the red [FILTER MISSING] light
turns ON and the [FRYER POWER] light turns OFF. Check to ensure that fryer under hood will not turn ON.
Reinstall the baffle filter. See Sections 4.02.2 & 4.02.3, Removal & Installation.
3. Charcoal (HEPA) Filter Test: Same procedure as #2 except perform for the charcoal filter. Reinstall filter.
See Sections 4.02.6, 4.02.7, Removal & Installation. Same procedure applies for a HEPA filter, if equipped.
4. E.A.C. Filter Test (N/A for HEPA Filter Version): Same procedure as #2 & #3 except remove the E.A.C. collector
cell, close and latch filter cover. Turn ON hood power. Verify that [WASH] light is ON, along with the amber
[FRYER POWER] light. Wait approx. two (2) minutes. A beeping tone alarm should begin sounding. Shortly,
the [FRYER POWER] light should turn OFF. Check to ensure that fryer under hood will not turn ON. Reinstall
the E.A.C. cell. See Section 4.02.4. & 4.02.5, Removal & Installation.
5. Filter Clogged Test: Perform this test ONLY after installing new charcoal filter. Start hood normally & allow
to run. Use cardboard or other material to completely block hood exhaust outlet, holding it firmly in place so
that no air is escaping. Within a few seconds, a continuous tone alarm should begin sounding & the [FRYER
POWER] light should turn OFF. Check to ensure that fryer under hood will not turn ON. Remove the obstruc
tion ... the alarm should silence & the [FRYER POWER] light should turn ON again.
Should any of these tests fail to yield the described results, contact a factoryauthorized service company and have the
unit evaluated and repaired. Any Giles Manufacturer’s Representative can provide information about nearby authorized
service providers, or call GILES Services at 8005544537 for assistance in locating a Representative or service provider.
The selfcontained fire extinguishing system in the hood must be maintained in accordance with the Standard for Wet
Chemical Extinguishing Systems, NFPA 17A and with the instructions of the system installer.
All inspection, maintenance, troubleshooting, repair & general servicing of the fire extinguishing system must be per
formed by an authorized Ansul® Service Company. Required maintenance activities are described in the subsequent
sections.
