39
5.01.2 E.A.C. Filter Cell Cleaning - continued
Cleaning &
Maintenance
Free Standing Ventless Hood
FSH-2 & FSH-2A-99
4. Carefully move cell to sink & rinse thoroughly, using hot water spray. Rinse ONLY, DO NOT scrub with
brushes.
5. Stand cell upright on end on a drain board, w/contact plate up ... allow it to drain and air dry over
night. The cell must be completely dry before being replaced in hood unit. If desired, a small electric
fan can be used to blow across the cell to help expedite drying.
6. Before replacing cell in the hood, inspect for broken/missing ionizer wires and bent fins. Broken
or missing wires need to be replaced promptly. Bent fins may be straightened by hand so that no
fins are touching adjacent fins.
IMPORTANT! ONLY Simple Green® Crystal Foaming Cleaner/Degreaser is recommended by GILES for cleaning the
E.A.C. cell in this manner. Other spray cleaners have not been evaluated and may contain corrosive ingredients that
may damage the metal, causing cell to fail or not perform properly. Such damages are not covered by the factory
warranty.
B. Alternate Cleaning Method − Soaking
The factoryrecommended product to use for cleaning the collector cell in this manner is Simple Green® Pro‐HD. It is a
readily available, biodegradable, nontoxic degreasing cleaner that is safe for use on aluminum. It performs well to
clean collector cells when diluted with water in a 1:12 ratio (e.g. 1/2 gal. cleaner to 6 gals clean water).
DO NOT use DISHWASHING DETERGENTS or CORROSIVE CLEANERS as they can contain ingredients that may damage
the metal cell components, causing failure or unsatisfactory performance. Such damages are not covered by the fac‐
tory warranty.
3. After preparing a quantity of degreaser solution sufficient to completely cover the cell in
the soaking container, carefully grasp cell & place it into the solution. Be sure that it is fully
submerged.
4. Allow cell to soak for approximately 20 minutes (no more than 30 mins), then lift slightly &
briefly agitate up & down in the solution to dislodge grease residue.
5. Carefully remove cell from container & follow Steps 4 thru 6 as described in the previous
section.
NOTE:
The degreasing solution may be used multiple times ... cover container with a lid or other suitable cover when not in
use to prevent contamination. Discard & replenish solution when a greasy film remains visible, floating on the liquid.
When soaking, always ensure that solution completely covers the cell ... add some water if needed.
1. The soaking method requires a suitable, leakproof container, such as a tall trash bin, recycle bin, plastic
tote, or the GILES soak tank*. Container must be large enough to hold the cell along with enough diluted
degreasing solution to submerge it completely for soaking.
2. Fill container with fresh water to a level that will basically cover the cell. Measure the water
as container is filled & note the quantity. Add Simple Green® Pro‐HD in the ratio of 1:12 to
the water (e.g. 8 gals. of water will require 85‐1/2 ozs. degreaser. Stir solution to mix.
* NOTE: The GILES soak tank (purchased separately, Item# 91123) is specifically designed & sized for
soaking the cell. Add 1/2 gal. of cleaner & fill tank to the marked “FILL” line with clean water.
