3.02 Control Box with Timer
Overview
Free Standing Ventless Hood
FSH-2 & FSH-2A-99
Item Description Function
*1
E.A.C. Filter Status
Indicators
[ON]
[WASH]
[CHECK]
LED light cluster indicates status of the Electronic Air Cleaner (E.A.C.)
system.
[ON] Turns ON when hood is poweredup. Indicates that the E.A.C.
system is powered & functioning normally to clean the air. This is the only
light ON when operating normally.
[WASH] Indicates excessive grease film buildup on collector fins (dirty),
collector cell is missing, poor connections, missing ionizer wires, etc.
Approximately 2 minutes after this light turns ON, a beeping tone alarm
sounds & power to fryer is shutdown.
IMPORTANT! Do not rely on this indicator as a signal for routine cleaning
... cell must be cleaned daily to maintain peak performance & extend
useful life of charcoal filters.
[CHECK] Indicates that collector cell has stopped operating properly ...
damaged & shorted to ground, fins are shorted due to excessive moisture,
etc. No alarm sounds & the fryer remains powered, but electronic air
cleaning is not functioning. Discontinue operation & inspect.
2 HOOD POWER Indicates that hood is powered and running.
3 FRYER POWER Indicates that power is being supplied to the fryer under the hood.
4 FILTER MISSING
Indicates that baffle and/or charcoal filter is missing or improperly installed.
HEPA filter if applicable.
5
Power Switch
PUSH‐TO‐START
Turns hood power ON and OFF. When hood fan is running sufficiently to
provide capture, power is supplied to the fryer. To start, press & momentarily
hold the top START portion of the switch ... release when fan starts &
switch springs back to remain ON. Hood must be restarted in this manner
after any lost of power.
*6 CHANGE SOON
Illuminates when the EAC Cleaning Timer enters [WARNING] mode. The
cell needs to be cleaned (or exchanged with a fresh cell) within the next
24 hours.
*7 CHANGE NOW
Illuminates when the EAC Cleaning Timer enters [TIMEOUT] mode. Allowed
time between cleanings (or exchange) has expired. The cell must immediately
be cleaned (or exchanged). An audible alarm sounds & both hood and
fryer are locked out, preventing continued operation until the appropriate
activities are performed.
*8 SNOOZE
Pressing this button delays [TIMEOUT] mode for 2 hours, thus allowing
the hood & fryer to continue operating to finish a cook cycle or meet cus
tomer demand. Two (2) snooze cycles are allowed, then the shutdown
will proceed.
* Not present on HEPA Filter Models
