Overview
3.01 Filter Chamber & Hood Front
Free Standing Ventless Hood
FSH-2 & FSH-2A-99
Item Description Function
*1 Filter Access Cover
Provides access to the filter chamber & plenum area.
Hood will not operate unless the cover is in place &
properly latched.
2 Charcoal Filter
Helps to control undesirable aromas generated during
cooking. It should be replaced monthly (approx). DO NOT
attempt to clean filter. To avoid lost time, keep a spare
filter (Giles #30248) for quick exchange.
NO FILTER COMPLETELY ELIMINATES COOKING ODOR.
3
Electronic Air Cleaner (E.A.C.)
Collector Cell
The E.A.C. system is an electronic air cleaner that
electrostatically captures greaseladen vapor & smoke
particulate generated by cooking. Power must be turned
OFF before removing the EAC cell for cleaning. To
maintain best air cleaning performance, the cell must
be cleaned daily. Fryer under hood is disabled if EAC
cell is missing, excessively dirty, or experiencing other
faults.
**4
HEPA Filter
(CE or Optional)
CE listed models or as option: EAC system is replaced by a
highefficiency HEPA Filter. The filter CANNOT be cleaned
& must be replaced periodically to maintain acceptable
performance. Fryer under hood is disabled if the HEPA
filter is missing or clogged. The HEPA filter is installed in
reverse of the illustration ... charcoal filter is placed below
the HEPA filter.
5 Baffle Filter
First stage of the air cleaning system. Easily removed for
daily cleaning. To prevent contact with electrical parts &
avoid electrical shock, DO NOT remove the baffle filter
while hood is powered.
6 Grease Drip Cup
Captures & collects grease condensate generated by the
baffle filter. It should be cleaned daily, or as needed.
7 Grease Drip Cup Safety Pin
Secures the grease drip cup to prevent it from uninten
tionally falling from the holding bracket.
8 Exhaust Air Diverter
Diverts hood exhaust air to the sides & rear. Allows for
operation of the unit in spaces with lower ceiling
heights.
9 Appliance Detector Link
Detects fire in the fryer & trips the fire extinguishing
system. Take care not to hit or bump the link ... doing so
may cause the fire extinguishing system to inadvertently
discharge.
