1. Introduction
1.1 Construction
1.02 Standard Features
1.03 Optional Features
1
Introduction
Free Standing Ventless Hood
FSH-2 & FSH-2A-99
Thank you for purchasing a new GILES Free Standing Ventless Recirculating Hood, Model FSH‐2 or FSH‐2A‐99 manufactured
by Giles Enterprises, Inc., Montgomery, Alabama (USA), hereafter referred to as "Giles". Giles ventless hood technology
is the result of extensive research, development & engineering. Every unit is thoroughly inspected & tested prior to
shipment to ensure it will operate flawlessly after installation. With proper care & maintenance the equipment should
provide years of troublefree service.
The hood is listed for use with fryers & pressure fryers, to remove greaseladen cooking vapors from the air, as well as
help to control objectionable odors which may be generated while cooking. It utilizes an electronic air cleaner (E.A.C.)
system, which electrically charges grease particulate in the air stream, then electrostatically captures it on collection
plates as the air passes through the collector cell. An activated charcoal filter provides a final filter stage to help control
cooking odor in the recirculated air.
To help protect your investment, we recommend taking a few moments to read this manual & familiarize yourself with
proper installation, cleaning & maintenance procedures. Adhering to these recommended procedures minimizes the
potential for costly downtime & equipment repair.
Please retain this manual for future reference.
Constructed of highgrade, formed & welded stainless steel sheet metal.
Three Stage Filtration: Three (3) different filter systems remove particulate & greaseladen vapor from the air stream.
Extinguishing System: Builtin Ansul® R‐102 fire extinguishing system protects against accidental fire in the cooking
appliance underneath the hood. Final field set up, charging & commissioning of the system
is the responsibility of the purchaser and must be provided by an authorized Ansul® dealer.
EAC Cleaning Timer: The system notifies user that it is time to clean the Electronic Air Cleaner (E.A.C.) collector cell.
DAILY cleaning is important to maintain peak air cleaning performance. If the cell is not
cleaned in a timely manner, the timer will shutdown the hood which also disables power to
the interlocked cooking appliance, preventing further operation cleaning is performed.
PushToStart Power: Hood & appliance will not automatically restart when power is restored after an interruption.
POWER switch must be pressed again to start. Complies with code requirements in some
jurisdictions.
Appliance Receptacle: Builtin, interlocked, NEMA 1550R power receptacle for the cooking appliance. Plug appliance
power cord directly into hood ... can help minimize onsite installation work. Maximum
appliance load = 50 amps.
HEPA Filter Model: Features a replaceable HEPA filter instead of the standard sustainable Electronic Air Cleaning
system.
