ENGLISH -

1.1 INTRODUCTION

DANGER:

Before using the appliance, read the accom-

panying “SINGLE DISC SAFETY WARN-

INGS” booklet carefully.

This manual forms an integral part of the ma-

chine itself. It must therefore be kept in a safe

place where it is accessible to all users (opera-

tors and maintenance personnel) throughout

the life of the machine until it is scrapped.

1.2 - INTENDED USE OF

THE MACHINE

WARNING:

This machine is for indoor use only.

DANGER:

Any other use releases the manufacturer

from liability for harm to persons and/or

property and invalidates any warranty

condition.

This machine is intended for commercial use,

for example in hotels, schools, hospitals, fac-

tories, shops, offices and rental businesses.

The machine has been designed and built:

for professional use, for cleaning floors and

carpets, for polishing floors, for sanding

floors (e.g. parquet and uneven surfaces).

1.3 - NON-INTENDED USE

OF THE MACHINE

WARNING:

The machine is not intended for outdoor

use.

DANGER:

do not wash floors with water above 50 °C;

- do not use diesel/petrol or corrosive de-

tergents to wash floors;

- do not wash and suck up corrosive, flam-

mable or explosive liquids, even if diluted.

2.1 COMPONENT

ASSEMBLY

2.1.a - Positioning the handle (Fig. 1)

For models with 4-screw handle fixing:

- Place the handle (1) on the base (2),

aligning the four holes on the handle with

the holes on the machine body.

- Tighten the screws (3) provided.

For models with 2-nut handle fixing:

- Unscrew the two nuts (4) from the ma-

chine body (5).

- Position the handle (6) by inserting the

pins present on the machine body (5).

- Tighten the nuts (4).

2.1.b - Electrical machine handle/

body connection (Fig. 2)

- Plug the handle into the machine body

by putting the plug (7) into the machine

socket (8);

For models equipped with a socket with

gasket (9) put the gasket in place be-

fore connecting the plug and tighten the

screws (10) supplied.

2.1.c - Assembling the cable reel

supports (Figs. 3/5)

Some models are equipped with cable reel

supports that must be assembled directly on

the shaft of the handle:

- Fit the short coupling (11) into the long

coupling (12) (Fig. 3).

- Tighten the screw (13) to the knob (14),

keeping the latter to the right (Fig. 4).

- The hook (15) of the support can be ro-

tated depending on usage (Fig. 5).

- Place one support at the top of the handle

and a second support at the bottom.
