www.ghibliwirbel.com
Professional Cleaning Machines Since 1968
EN -
3
Technical data
* The washing width is intended with the machine operating and the brush pressed down.
40 / 45 SM 55 40 / 45 SD 55
Type of use Operator on ground
Characteristics
Power supply Battery Battery
Power supply voltage See technical data plate
Installed load 750 W 900 W 1090 W 1240 W
Forward movement Manual Tractioned
Washing width * 530 mm 530 mm
Drying width 750 mm 750 mm
Theoretical hourly working capacity 2120 m
2
/h 2650 m
2
/h
Brushes / Pad
Diameter / Number 530mm/21” 530mm/21”
Motor power / number 350 Wx1 500 Wx1 350 Wx1 500 Wx1
Motor speed 115 rpm 115 rpm.
Specific pressure 18 gr/cm
2
18,8 gr/cm
2
18 gr/cm
2
18,8 gr/cm
2
Carter weight 26 Kg 27,2 Kg 26 Kg 27,2 Kg
Aspiration
Motor power 400 W 550 W
Negative pressure 1189 mmH
2
O 1791 mmH
2
O
Air flow rate 28 l / sec 30 l / sec
Noise level
Min. 57 dB (A)
/ Max. 63 dB (A)
Traction
Engine power --- 180 W
Tank
Recirculation No No
Solution capacity 40 / 45 l 40 / 45 l
Recovery capacity 42 / 47 l 42 / 47 l
Dimensions (lxwxh) without wip-
er
1210 x 560 x 1040 mm 1210 x 560 x 1020 mm
Vibrations ISO 5349 m/sec
2
< 2,5 < 2,5
Weight
Empty weight 90,5 Kg 91,7 Kg 109 Kg 110,2 Kg
Weight with batteries 143,5 Kg 144,7 Kg 189 Kg 190,2 Kg
Weight in running order GVW 188,5 Kg 189,7 Kg 234 Kg 235,2 Kg
Man_round-rapid_ROUND45SM-SD-Rapid_3ed_01-2019_49026700.indd 3 28/01/19 09:49
