ENGLISH -

- Wash the inside of the tank, leaving the

drain hose open and adding clean water

through the top opening.

- When cleaning is complete, lift the tube

(15), leaving the tap (53) open; couple

the tube in its recesses.

- To completely drain the water from the

tank (5) disconnect the tube (57) from the

quick connector (58) then turn the con-

nector downwards, letting the water drain

completely; or remove the filter cover

(59).

12.1.c - Cleaning the recovery water

tank (Fig. 18)

WARNING:

At the end of the washing operations, it

is compulsory to clean the recovery wa-

ter tank to prevent deposits or scaling

and the proliferation of bacteria, odours

or mould.

- Drain the recovery water as shown in the

relative paragraph, positioning the ma-

chine over a drain outlet.

- Remove the cover (6).

- Leaving the hose (12) lowered and the

cap off, pour water into the tank (14)

through a hose, cleaning it until clean wa-

ter comes out of the drain hose.

- Clean the level probes (55) using a damp

cloth, taking care not to deform them.

- Replace all the components in reverse

order.

12.1.d - Cleaning the squeegee (Fig.

In order to clean the squeegee correctly (11),

it is necessary to remove it as follows:

- Disconnect the hose (13) from the squee-

gee (11).

- Loosen the knobs (32) and remove the

squeegee (11).

- Wash the squeegee and in particular the

rubber blades (60) and the inside of the

aspiration connector (33).

NOTE:

If, during washing, it is clear that the rubber

blades (60) are damaged or worn, it is neces-

sary to replace them or turn them over.

- Replace all the components in reverse

order.

OPERATIONS TO

PERFORM WHEN

NECESSARY

12.1.e - Cleaning the clean water filter

(Fig. 19)

NOTE:

Before cleaning the lter, make sure the

clean water tank is empty.

- Unscrew and remove the cover (59).

- Remove the filter (17) and wash it in run-

ning water.

- Refit the filter (17) in its seat, then tighten

the cover (59).

12.1.f - Replacing the brush (Fig. 20)

It is necessary to replace the brush when it is

worn more than 2 cm or it must be replaced

depending on the type of floor to be washed;

to replace it proceed as follows:

- Lift up the brush using the pedal as

shown in the relative paragraph.

- Insert a hand under the brush holder unit

(9); to release the brush, turn it abruptly

in the direction of rotation.

- Replace the brush, coupling it manually

to the brush holder flange (9).

- Lower the brush-holder ange (9) using

the pedal, as shown in the relative para-

graph.

- Press the button (45 Fig. 9) to enable the

controls.

- Press the button (52 Fig. 9) to enable

brush rotation.

- Act on the touch sensor (20) positioned

on the handle to start the rotation of the

brush.
