19
TECHNICAL DATA {1/3}
“RR 300 FD” Versions 110 130
Performance
Maximum hourly washing capacity 8800 m²/h 10400 m²/h
Cleaning width 1100 mm 1300 mm
Drying width 1360 mm 1360 mm
Max. travel speed 9 km/h
Max. reverse speed 4.5 km/h
Max. working speed 8 km/h
Max. gradient 16%
Noise level (EN ISO 11201/2010)
Sound pressure level in operating position dB(A) 68,4
Vibrations (EN ISO 13754/2008)
Level of the frequency-weighted accelerations m/s² < 2,5
Brushes
Brush (no.- type) 2 - disc 3 - disc
Position Between front and rear wheels
Turning speed (RPM) 160-170 160-170
Lifting electric
Diameter 560 mm 490 mm
Pressure (weight) 0-115 kg 0-90 kg
Waste container
Capacity
Squeegee
Type oating
Vacuum (squeegee vacuum) mm/H2O 1500
Lifting and lowering electric
Tanks
Clean water (solution) 280 L
Dirty water (recovery) 305 L
Steering
Type
with steering wheel/mechanics on front
wheel
Minimum space for U-turn 2550 mm
Electric motors
Drive motor
1 - 36 V.AC - 2000 W
Brush rotation motor 2 - 36 V - 400 W 3 - 36 V - 400 W
Vacuum motor 2 - 36 V - 580 W
Total power 3960 W 4360 W
Batteries
Battery (type)
equipped with automatic top-up and
distilled water tank
No./V/Ah 1 - 36 - 525
Dimensions (length X width x height) 620 x 610 x 555 mm
Peso | Weight | Poids | Gewicht 603 kg
Battery water distilled water
*Battery life (h) 4.40’ 4.10’
*Battery life may vary, depending on the type of battery and the use of the machine
