33
IP CONTROL - MAIN PAGE
The 16x16 DVI Matrix supports IP-based control using an integrated Web
interface. To access this feature, an IP address, subnet, gateway, and port
number need to be set on the 16x16 DVI Matrix (Default IP: 192.168.0.70
Subnet: 255.255.255.0 Gateway: 192.168.0.1 Port: 80). Consult the network
administrator to obtain the proper IP address and settings for this product to
properly communicate on the network.
The IP control setting can be confi gured via the RS-232 control interface. Once
this has been accomplished, access to the Web Interface is possible.
Simply type the IP address that was assigned to the product in a web browser to
access the Main Page. It should look like the image below.
MAIN PAGE
The Main Page will display the current status and can also be used to create
routes.
To create a new route, follow the steps below:
1. Select which outputs will display the source by clicking on each check box.
2. Select the radio button of the input that will be routed to each output.
3. Click the SWITCH button to update the new routing confi guration.
This page will automatically refresh every minute. However, at anytime the
“Refresh” button can be pressed to refresh the status of the Matrix.
