8
Installing the Battery
The Remote Control unit ships with two batteries. One battery is required for operation
and the other battery is a spare.
1. Remove the battery cover on the back of the IR Remote Control unit.
2. Insert the included battery into the open battery slot. The positive (+) side of the
battery should be facing up.
3. Replace the battery cover.
Setting the IR Channel
The IR channel on the IR Remote Control must match the IR channel used by the DVI
16x16 Matrix. For example, if both DIP switches on the IR Remote Control unit are set to
IR channel 0 (both DIP switches down), then the 16x16 DVI Matrix must also be set to IR
channel 0. See page 37 for information on how to change the IR channel on the DVI 16x16
Matrix.
Remote Channel 2: Remote Channel 3:
Channel 0 (default): Remote Channel 1:
DIP switchesBattery slot
1 2
ON
1 2
ON
1 2
ON
1 2
ON
1 2
IR REMOTE CONTROL
WARNING: Risk of explosion if battery is replaced by an incorrect
type. Dispose of used batteries according to the instructions.
