page | 8
IR Remote Control Unit
ID Name Description
1 Power
Press this button to toggle between On and Off power modes.
Powering on the unit via IR from the HDBaseT™ receiver is not
possible as the link is not active when the unit is in standby mode.
This button is fully functional when communicating directly with the
main unit.
It is possible to power off the 5x1 switcher/scaler from the
remote location via the IR remote. The scaler, however, cannot
be turned back on from the remote location.
2 Mute Toggles mute/un-mute of both analog and HDMI outputs.
3 Inputs
Press these buttons for discrete source selection. The ◄ and ►
buttons can be used to cycle between inputs in numerical order.
4 ADJ Performs an auto-sync action for the VGA input.
5 RES
Resolution will cycle on each press of this button based on
available output resolutions. Long pressing this button will reset the
resolution to 720p 60Hz.
6 Menu buttons
MENU: Activates/Deactivates OSD menu.
EXIT: Exit OSD menu or cancel current operation.
OK: Option conrmation
UP/DOWN/LEFT/RIGHT: OSD menu navigation
7 Main Volume
Decrease () or increase () audio output volume (HDMI,
HDBaseT™, and Audio out ports).
8 Mic Volume
Decrease () or increase () MIC input audio volume.
Switcher Remote
E
RMT-MF-51A
OK
Main Mic
Volume
Input
HD 1 HD 2 HD 3
DP
VGA
Auto
Adj
Res
Menu
Exit
Mute
1 2
3
7
4
5
6
8
