10 INSTALL GRILLE PANEL
Raise the grille panel to the stop position.
Remove 4 screws on bottom trim; retain
all screws.
Remove bottom trim.
NOTE: Stainless steel and acrylic panels
are covered with a protective film. Remove
the film before installing the panel.
Slide panel over the metal backer panel
and under the trim.
If necessary, tap with a wood block until
panel slips under the top trim piece.
Reassemble bottom trim. Tighten screws.
Raise
Grille
Panel
8 SECURE REFRIGERATOR
TO CABINETS
Whenever possible, perform this step for
anti-tip security.
The refrigerator must be secured to prevent
tipping.
Raise the grille panel to access case trim.
Drive a screw through the trim and into the
adjacent cabinet using holes provided.
Follow the same procedure on the opposite
side.
Drive Screws
Through Case Trim Into
Adjacent Cabinets
Raise Grille Panel
to Stop Position
9 ADJUST DOOR SWING
NOTE: This refrigerator has a 2-position door
stop. When space does not allow the door to
swing open fully to 130°, you may change the
door swing to a 90° opening.
SKIP THIS STEP IF DOOR OPENING IS
SATISFACTORY FOR YOUR INSTALLATION
SITUATION.
Open the door to view the bottom hinge.
Note the door stop pin location. The pin is
factory installed in the 130° position.
Partially close the door. From above, use a
flat-head screwdriver to unscrew the door
stop pin and reinstall into the 90° position.
90°
130°
Hinge
Door
Interior
Installation Instructions
32
