49-4000291 Rev 3 9
Installation Instructions
INSTALL THE UNDER SINK
MOUNTING HARDWARE (CONT.)
7LJKWHQWKHWKUHHXSSHUPRXQWLQJULQJVFUHZVLQWRWKH
support flange.
IF CONNECTING TO A DISHWASHER
If you are connecting to a dishwasher, complete this step.
If a dishwasher is not to be connected, skip to ATTACH
THE DISCHARGE ELBOW section and continue.
• 6HWWKHGLVSRVHURQWKHIORRU3ODFHLWRQLWVVLGHRQD
SURWHFWHGVXUIDFH8VHDEOXQWLQVWUXPHQWVWHHOSXQFK
or wooden dowel), to knock out the entire dishwasher
GLVFKDUJHSOXJ'RQRWXVHDVFUHZGULYHURUVKDUS
instrument. When knockout plug falls into disposer, you
may remove it or simply grind it up when the disposer
LVXVHG7KLVZLOOQRWGDPDJHWKHGLVSRVHULQDQ\ZD\
but may take some time to grind, over the course of
several uses.
8VHDSXQFKRU
GRZHORQO\'RQRW
use a screwdriver or
sharp instrument.)
ATTACH THE DISCHARGE ELBOW
• Slide the discharge flange and then the discharge gasket
onto the discharge elbow. Insert the discharge elbow and
gasket into the disposer discharge outlet and attach the
flange assembly to the disposer with the two screws.
NOTE: Some installations may require a straight pipe
or flexible drain pipe connection. Consult a licensed
plumber as needed.
'LVFKDUJH2XWOHW
Gasket
Screws
)ODQJH
'LVFKDUJH
Elbow
Screws (3)
