28
WALL SECTION – DETAILED SIDE VIEW
WINDOW, 2" CURTAIN OR PANEL WALL INSTALLATION WITH RAG REAR GRILLE EXTENDED BEYOND OUTER WALL SURFACE
Cord Set Connected Sub-Base Connected
ROOM
CABINET
Gasket and
caulk around
perimeter of
wall case all
four sides
where it joins
the building
WALL CASE
OUTDOOR
GRILLE
Gasket and
caulk around
perimeter of
wall case all
four sides
where it joins
the building
CASE ANGLE (FIELD SUPPLIED)
RAB71 22-1/4"
RAB77 22-3/8"
WITH RAG61-66
RAB71 21-1/8"
RAB77 21-1/4"
WITH RAG60
RAB71
16"
RAB77
16-1/4"
RECEPTACLE
(BY OTHERS)
MIN. 2 SUPPORTS
FIELD SUPPLIED
FLOOR
USE NO
SCREWS IN
BOTTOM OF
CASE
16"
ROOM
CABINET
WALL CASE
OUTDOOR
GRILLE
CASE ANGLE (FIELD SUPPLIED)
RAB71 22-1/4"
RAB77 22-3/8"
WITH RAG61-66
RAB71 21-1/8"
RAB77 21-1/4"
WITH RAG60
RAB71
16"
RAB77A
16-1/4"
16"
WALL OR
WINDOW
GASKET
(FIELD
SUPPLIED)
SIDE
CHANNEL
(RAK204)
SUB-BASE
POWER SUPPLY
CONDUIT
(ALTERNATE ENTRY)
LEVELING LEG
3" MIN.
5" MAX.
FLOOR
2020 Data Manual 2002 11/7/02 3:19 PM Page 28
