12 49-5001072 Rev. 0
Installation Instructions
4. Connect Exhaust Hose to the
Window Panel
Place the Air Conditioner 20” from the wall and
any other obstructions. Extend the hose so that it
UHDFKHVWKH:LQGRZ.LW,QVHUWWKH([KDXVW+RVH
Adapter into the opening in the Window Kit and
slide it into the locking position. Ensure that the
hose runs straight to the window with no excess
extension. Use the small screw to attach the
exhaust hose assembly to the window sealing plate
assembly.
Important: The Air Conditioner must be vented to
the outside. Do not use a longer hose or extend the
hose included with the Air Conditioner or the unit
will not cool properly and will overheat.
INSTALLATION INSTRUCTIONS
5. COMPLETE INSTALLATION
1. Plug the power cord into a grounded 3
prong outlet.
2. Press the Reset button on the plug to
ensure the safety plug is providing power to
the Air Conditioner.
3. Allow 20” of clearance around the Air
Conditioner for proper air circulation
4. When removing the Air Conditioner, be sure
to remove the Window Kit.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong from the
power cord plug.
Do not use an adapter.
Do not use an extension cord.
Failure to do so can result in death, fire or
electrical shock.
RESET
TEST
50cm
90cm
20”
