MAX ELEVTN: The highest elevation reached since the last

reset.

MAX SPEED: The highest speed reached since the last reset.

MAX TEMP: The maximum temperature recorded in the last

24 hours from a compatible temperature sensor.

MIN ELEVTN: The lowest elevation reached since the last reset.

MIN TEMP: The minimum temperature recorded in the last

24 hours from a compatible temperature sensor.

MOV'N AVG: The average speed while moving for the current

activity.

MOV'N TIME: The total time moving for the current activity.

NEXT DEST: The next point on the route. You must be

navigating for this data to appear.

NEXT DIST: The remaining distance to the next waypoint on the

route. You must be navigating for this data to appear.

NEXT ETA: The estimated time of day when you will reach the

next waypoint on the route (adjusted to the local time of the

waypoint). You must be navigating for this data to appear.

NEXT ETE: The estimated time remaining until you reach the

next waypoint on your route. You must be navigating for this

data to appear.

ODOMETER: A running tally of the distance traveled for all trips.

This total does not clear when resetting the trip data.

OFF COURSE: The distance to the left or right by which you

have strayed from the original path of travel. You must be

navigating for this data to appear.

OVER'L SPD: The average speed for the current activity,

including both moving and stopped speeds.

SPEED: The current rate of travel.

STOP TIME: A running tally of the time spent not moving since

the last reset.

SUNRISE: The time of sunrise based on your GPS position.

SUNSET: The time of sunset based on your GPS position.

TEMPERATURE: The temperature of the air. Your body

temperature affects the temperature sensor. Your device

must be connected to a tempe sensor for this data to appear.

TIME: The time of day based on your current location and time

settings (format, time zone, daylight saving time).

TO COURSE: The direction in which you must move to get back

on the route. You must be navigating for this data to appear.

TOTAL TIME: A running tally of the total time spent moving and

not moving since the last reset.

TOT ASCENT: The total elevation distance ascended during the

activity or since the last reset.

TOT DESCNT: The total elevation distance descended during

the activity or since the last reset.

TRIP ODOM: A running tally of the distance traveled since the

last reset.

TURN: The angle of difference (in degrees) between the bearing

to your destination and your current course. L means turn

left. R means turn right. You must be navigating for this data

to appear.

VERT SPEED: The rate of ascent or descent over time.

VMG: The speed at which you are making progress into the

wind.

VSPD DEST: The rate of ascent or descent to a predetermined

altitude. You must be navigating for this data to appear.

Applied Ballistics Glossary of Terms

NOTE: The Applied Ballistics feature is available only on the

Foretrex 701 device.

Shooting Solution Fields

DOF: The direction of fire, with north at 0 degrees and east at 90

degrees. Input field.

TIP: You can use the compass to set this value by pointing

the top of the device toward the direction of fire. The current

compass value appears in the DOF field. You can select

ENTER to use this value. You can manually enter a value by

selecting or .

NOTE: The DOF is used only for calculating the Coriolis

effect. If you are shooting at a target less than 1,000 yards

away, this input field is optional.

ELEVATION: The vertical portion of the aiming solution,

displayed in milliradians (mil) or minute of angle (MOA).

RNG: The distance to the target, displayed in yards or meters.

Input field.

W 1/2: The wind speed 1, wind speed 2, and wind direction. For

example, if the wind direction is DIR 9:00, the wind is blowing

left to right as viewed by the shooter. Input field.

NOTE: The wind speed 2 field is optional. Using both wind

speed 1 and wind speed 2 is not an effective way to account

for different wind speeds at different distances between you

and the target. Using these fields is a way to bracket (isolate)

the wind values and calculate minimum and maximum

windage values for the solution.

WINDAGE 1: The horizontal portion of the aiming solution

based on the wind speed 1 and wind direction, displayed in

milliradians (mil) or minute of angle (MOA).

WINDAGE 2: The horizontal portion of the aiming solution

based on the wind speed 2 and wind direction, displayed in

milliradians (mil) or minute of angle (MOA).

Additional Output Fields

AERO JUMP: The amount of the elevation solution attributed to

aerodynamic jump. Aerodynamic jump is the vertical

deflection of the bullet due to a crosswind. If there is no

crosswind component or wind value, this value is zero.

COS INCL: The cosine of the inclination angle to the target.

DROP: The total drop the bullet experiences along its flight path,

displayed in inches.

H COR EFFECT: The horizontal Coriolis effect. The horizontal

Coriolis effect is the amount of the windage solution

attributed to the Coriolis effect. This is always calculated by

the device, although the impact may be minimal if you are not

shooting at extended range.

LEAD: The horizontal correction needed to hit a target moving

left or right at a given speed.

TIP: When you enter the speed of your target, the device

factors the necessary windage required into the total windage

value on the Applied Ballistics page.

MAX ORD: The maximum ordinance. The maximum ordinance

is the maximum height above the axis of the barrel that a

bullet will reach along its flight path.

MAX ORD RNG: The range at which the bullet will reach its

maximum ordinance.

REM ENERGY: The remaining energy of the bullet at target

impact, displayed in foot-pounds of force (ft. lbf) or joules (J).

SPIN DRIFT: The amount of the windage solution attributed to

the spin drift (gyroscopic drift). For example, in the northern

hemisphere, a bullet shot out of a right-hand twist barrel will

always deflect slightly to the right as it travels.

TOF: The time of flight, which indicates the time required for a

bullet to reach its target at a given range.

V COR EFFECT: The vertical Coriolis effect. The vertical

Coriolis effect is the amount of the elevation solution

attributed to the Coriolis effect. This is always calculated by

the device, although the impact may be minimal if you are not

shooting at extended range.

10 Appendix
